This threaded tool bar is listed in the catalogue anti-vibration series. The cutaway drawing shows an internal damper, while the dimension drawing identifies the bar diameter d, length L, thread M and front dimension D.
Confirm mating tool-head compatibility using the M8 connection and the source drawing. The source does not identify this model as a carbide bar or provide a quantified vibration-reduction result.
The catalogue image is a series illustration, not confirmation of the exact supplied configuration. Confirm the tool head, inserts and accessories required when requesting a quotation.
Technical reference: 2023 supplier catalogue, PDF page 4. Availability, price, MOQ and lead time require confirmation.
